Details
- Motorise Adjust Sawblade Up & Down
- Manually Adjust 45 Degree
- 45 LED Display
Specification:
- Dimension sliding table : 3200 x 370mm
- Max. Length Panel Cut : 3000mm
- Max. Height Panel Cut : 75mm
- Tilting angle saw blade : 45*
- Diameter of Saw Blade : 300mm
- Diameter Scoring Saw Blade : 120mm
- Diameter scoring saw blade : 120mm
- Speed of main saw blade : 4500/5800rpm
- Speed of scoring saw blade : 6000/8000rpm
- Spindle diameter : 30mm
- Main motor : 5.5kw / 7.5Hp
- Scoring motor : 0.75kw
- Voltage : 415V /50Hz 3Phase
- Body Packing Size : 2150mm x 1100mm x 1100mm
- Table packing size : 3050mm / 3250mm x 420mm x 280mm
View more about Sliding Table Saw Machine Q-32 on main site
